Prior to installation, carefully read the user's manual and follow these procedures: GA-P85-D3 Motherboard Block Diagram 1 PCI Express x16 CPU CLK+/- (100 MHz) PCIe CLK (100 MHz) LGA1150 CPU HDMI DMI 2.0 x16 PCI Express Bus DDR3 1600/1333 MHz Dual Channel Memory FDI Dual BIOS LAN RJ45 PCIe CLK (100 MHz) x1 PCI Express Bus x1 4 SATA 6Gb/s Realtek® GbE LAN 2 SATA 3Gb/s Intel® B85 4 USB 3.0/2.0 x1 x4 PCIe to PCI Bridge 8 USB 2.0/1.Ĭhapter 1 1-1 Hardware Installation Installation Precautions The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD).
GIGABYTE MOTHERBOARD MANUALS DRIVER
GA-P85-D3 Motherboard Layout ATX_12V_2X4 CPU_FAN COMA KB_MS HDMI LGA1150 ATX R_USB R_USB30 USB_LAN SYS_FAN3 DDR3_1 DDR3_3 GA-P85-D3 PCIEX16 DDR3_2 Realtek® GbE LAN SYS_FAN1 DDR3_4 PCIEX1 F_USB30 AUDIO PCI1 CODEC Intel® B85 PCI2 BAT iTE® Super I/O PCI3 B_BIOS PCI4 SATA3 SATA2 0 2 1 3 4 5 PCIe to PCI Bridge M_BIOS PCIEX4 SPDIF_IN CLR_CMOS F_USB1 F_AUDIO COMB SPDIF_O F_USB2 LPT SYS_FAN2 F_PANEL Box Contents 55 55 55 55 GA-P85-D3 motherboard Motherboard driver disk User's Table of Contents GA-P85-D3 Motherboard Layout.4 GA-P85-D3 Motherboard Block Diagram.5 Chapter 1 Hardware Installation.6 1-1 1-2 1-3 1-4 1-5 1-6 1-7 Installation Precautions. Changes to the specifications and features in this manual may be made by GIGABYTE without prior notice. Disclaimer Information in this manual is protected by copyright laws and is the property of GIGABYTE.
The trademarks mentioned in this manual are legally registered to their respective owners. Press on this item and select Yes.Motherboard GA-P85-D3 Motherboard GA-P85-D3 Copyright © 2013 GIGA-BYTE TECHNOLOGY CO., LTD.
Select No or press to return to the BIOS Setup Main Menu.
This saves the changes to the CMOS and exits the BIOS Setup program. (Default: Disabled)Īllows you to determine whether to let the onboard graphics enter standby mode to decrease power consumption. (Default: Auto)Īllows you to select whether to allow the system to adjust power consumption when it is in shutdown, idle, or standby state in order to comply with the CEC (California Energy Commission) 2019 Standards. Auto lets the BIOS automatically configure this setting. When the power supply is at low load, a self-protection will activate causing it to shutdown or fail. Note: When using this function, avoid inadequate shutdown from the operating system or removal of theĪC power, or the settings may not be effective.Įnables or disables dummy load. Wake up hour/minute/second: Set the time at which the system will be powered on automatically. Wake up day: Turn on the system at a specific time on each day or on a specific day in a month. If enabled, set the date and time as following:
